Sprocket Detailed Product Introduction

1. Product Overview

2. Raw Material Options & Advantages

1. C45/45# Carbon Steel (Most Popular)

   High tensile strength, low cost, easy heat treatment. Tooth surface induction quenched to 45–55 HRC, outstanding wear resistance for general heavy-duty machinery, conveyors and agricultural machines.

2. 304/316 Stainless Steel

   Full rust & corrosion resistance, food-grade and acid-proof. Ideal for food processing, chemical plants, marine and humid workshop environments.

3. Alloy Steel (40Cr)

   Higher hardness and impact resistance, suitable for high-torque, high-speed and heavy-load working conditions like mining and construction machinery.

4. Cast Iron HT200/HT250

   Good shock absorption, low noise, low price, applied to low-speed light-load conveying equipment.

5. Nylon PA66+Glass Fiber Plastic Sprocket

   Light weight, self-lubricating, ultra-low noise, used for small office equipment and light automated lines.

3. Production & Processing Technology

1. CNC precision turning for inner bore, hub and keyway to guarantee concentricity, no shaking during operation.

2. Professional gear hobbing machine for tooth processing, smooth tooth profile, tight fit with chains to reduce abrasion and tooth skipping.

3. Heat treatment: Induction hardening only on tooth surface, retain hub toughness to avoid fracture under impact load.

4. Surface treatment options: Black oxide, zinc plating, sandblasting, polishing to prevent rust and extend service life.

5. Finished bore with standard keyway, set screw holes for direct installation; rough bore and taper lock bush types are customizable.

4. Main Product Classification

• By row: Single row sprocket, double row sprocket, triple row sprocket

• By structure: Plate sprocket (without hub), hub sprocket, welded sprocket, split sprocket, tension sprocket

• By application: Drive sprocket, driven sprocket, conveyor sprocket, motorcycle/bicycle sprocket, timing engine sprocket

• By pitch: Standard roller chain sprocket, double pitch conveyor sprocket, silent chain sprocket

5. Core Performance Advantages

1. Constant transmission ratio, nearly zero slip rate, stable power output compared with belt drive.

2. Adapt to harsh environments: high temperature, dusty, muddy, humid workshops.

3. Large torque bearing capacity, works reliably under heavy overload.

4. Simple structure, easy disassembly and maintenance, lower replacement cost.

5. Low noise after regular lubrication, long service life when matched with correct chains.

6. Wide compatibility, standard sizes interchangeable with global brand chains.

7. Full customization support: custom tooth number, bore size, hub length, mounting holes and surface coating.

6. Wide Application Fields

• Logistics & Warehouse: Dock levelers, roller conveyors, automated sorting lines, pallet transport equipment

• Agricultural Machinery: Tractors, harvesters, rice transplanters, feed processing machines

• Construction & Mining: Crushers, screening machines, asphalt mixing equipment

• Automotive & Motorcycle: Bike transmission, motorcycle drive sets, engine timing systems

• Food & Beverage Production: Packaging lines, conveyor ovens, food transport chains

• General Automation: Printing machines, textile equipment, packaging machinery

7. Key Technical Parameters for Customization

• Chain pitch: 04C,06B,08A,08B,10A,12A,16A,20A,24A,08B-1 to 24B-3

• Tooth quantity: 8–120 teeth as customer demand

• Bore type: Rough bore, finished bore with keyway, taper lock bore

• Surface hardness: 40–58 HRC (hardened teeth)

• Surface finish: Blackened, galvanized, polished

• OEM service: Custom drawing processing, logo engraving, special hub size
